Discover the advanced MX-10A Metal Wire Drawing Machine by Times MinXin, designed for ultra-fine wire processing with precision control. Features include independent tension control, automatic surface reduction calculation, and the ability to handle gold, silver, copper, and stainless steel wires as thin as 13 μm. Achieve high production rates with our state-of-the-art technology.
Features:
1. Independent tension control, 1 g - 50g can be set, and the height can be set and constant
2. Single group operation and multiple groups of simultaneous operation are optional
3. Full touch screen operation, digital control
4. Unique all excellent control technology. After online, just press it gently, and the system will Implement the full
optimization control function, calculate the surface reduction rate to the full optimization state, and raise the
High line drawing success rate and increased production capacity
5. Automatic surface reduction rate calculation, numerical visualization of each round, real-time online feedback
of surface reduction rate and speed of each mold
6. 100 sets of memory menu storage
7. The most advanced servo control technology is adopted, which is stable and reliable
8. Special innovative design, setting out and take-up meter function, real-time feedback length
9. Maximum speed 1200m I min
10. Precise calculus control makes the operation more stable and the production capacity
improved, which is suitable for 15 μm ultra thin line condition
11. Mold wear identification function, the equipment can detect mold wear
online and predict in advance
Machine specification:
model: MX-10A
Power Supply: Three phase 380V 200V 50hz/60hz
Applicable materials: Gold,silver, coppers, stainless steel and other ultra-fine metal wires
Finished wire diameter: 13-50 μ m / 50-100 μ m
Wire extension speed: MAX1200m/min(Commonly used: 100-900m/min)
Tension Range: 1-50g
