Discover the CDM-01D Two-Way Metal Wire Drawing Machine by Times MinXin, designed to double efficiency with two-way drawing technology. This high-precision machine ensures synchronized line movement, reduces unbalanced loads, and offers precise control for ultra-fine wire processing. Ideal for gold, silver, copper, and stainless steel wires with output diameters as fine as 1mm. Space-saving design and advanced control panel make it perfect for high-efficiency operations.
Features:
1. Two-way drawing is adopted to double the efficiency
2. Telescopic processing is not only for line movement, but also for eye film installation, which reduces the
longitudinalwidth of the machine and saves space
3 .Keep fixed when the spool is not moved in line.
4. The high-precision control makes the line movement of thetwo parts reach precise synchronization, and
realizes thestraight line extension of the material straight out of the eye film and straight around the reel.
5. The unbalanced load which affects the material quality is reduced.
6. The control panel can pre-set the conditions of stretching line processing, through simple operation can
pursue theideal stretching line processing, tension can also be directly input value setting.
7. Through the reduction rate can continue to calculate the finished wire diameter, the calculated wire
diameter exceeds the upper limit set value, the machine will automatically stop, can prevent the
occurrence of bad wire.
Machine specification:
model: CDM-01D
Power Supply: Three phase 380V 200V 50hz/60hz
Power: 35KW
Applicable materials: Gold, silver, coppers, stainless steel and other ultra-fine metal wires
Input maximum wire diameter: 8mm
Output maximum wire diameter: 1mm
