設備特點：1. 全程采用PLC程序及數字，中文顯屏界面說明指導，可減少伸線中線材之滑差，及增強線材的美觀及質量。PLC program and digital are used in the whole process, and the Chinese screen interface is used for instruction, which can reduce the wire slip
設備特點：
1. 全程采用PLC程序及數字，中文顯屏界面說明指導，可減少伸線中線材之滑差，及增強線材的美觀及質量。
PLC program and digital are used in the whole process, and the Chinese screen interface is used for instruction, which can reduce the wire slip in wire drawing and enhance the beauty and quality of wire rod.
2. 設備運行中作中，自動跟蹤調整做自動補償，從而達到產品始終與一的局品質，局效率。
During the operation of the equipment, automatic tracking adjustment and automatic compensation are made to achieve the high quality and high efficiency of the product.
3. 設備具有多項安全防范檢測電控系統設施及預警/報警燈，同時中文顯屏指示功能。確保操作人員及設備運行穩定性和產品合格率。
The equipment has a number of security detection, electronic control system facilities and early warning / alarm lights, as well as Chinese display and indication functions. Ensure the operation stability of operators and equipment and product qualification rate.
4. 操作簡單，使用方便安全，易學易懂即會使用，對操作人員技術性要求低(可實現1人多機操作管理)。
It is easy to operate, easy to use and safe to use, easy to learn, easy to understand, and low technical requirements for operators (it can realize the operation and management of more than one person).
5. 燥音低，可根據各線材質韌性無級調速；結構緊湊，運行平穩，維護簡便。
Low dry sound, stepless speed regulation according to the material toughness of each line; compact structure, stable operation and simple maintenance.
6. 該設備精鋼結構，體積小.占地少拆裝方便。
The equipment has fine steel structure, small volume, less occupation and convenient disassembly and assembly.
7. 全部采用松下伺服驅動與控制，PLC可編程系統控制，觸摸屏人機界面。
All adopt Panasonic servo drive and control, PLC programmable system control, touch screen human-machine interface.
8. 程序空間大，工藝程序的編輯、移植、刪減、增加既清晰直觀又方便快捷。
The program space is large, and the editing, transplanting, deleting and adding of the process program are clear, intuitive and convenient.
規格參數：
| 最大進線直徑： | 0.200mm | Maximum inlet diameter: | 0.200mm |
| 最小出線直徑： | 0.050mm | Minimum outlet diameter: | 0.050mm |
| 最大出線速度： | 600m/min | Maximum outlet speed: | 600m/min |
| 最多拉伸道次： | 15道 25*6 | Maximum stretch passes: | 15 25*6 |
| 配模延伸率： | 5% | Mold elongation: | 5% |
| 最大塔輪直徑： | 45mm | Maximum wheel diameter: | 45mm |
適應收放線盤(D1*D*L1*L*d): | ￠110*￠110*72*69*15 ￠88*￠80*52*50*￠78 | Adapt to take in and pay out reel (D1*D*L1*L*d): | ￠110*￠100*72*69*15 ￠88*￠80*52*50*￠78 |
| 各塔輪速比： | 1.09% | Speed ratio of each tower wheel: | 1.09% |
| 配模減面率： | 10% | Surface reduction rate of die matching: | 10% |
| 放線裝置： | 主動放線及D160帶阻尼被動放線（接200/25中拉） | Pay off device: | Active stringing and D160 passive Stringing with damping (connected to 200 / 25 medium tension) |
| 主動放線電機功率： | 0.4KW松下伺服電機 | Power of active pay off motor: | 0.4KW Panasonic servo motor |
| 主電機功率： | 3KW松下伺服電機 | Main motor power: | 3KW Panasonic servo motor |
| 排線電機功率： | 0.4KW松下伺服電機 | Winding motor power: | 0.4KW Panasonic servo motor |
| 收線電機功率： | 1.5KW松下伺服電機 | Take up motor power: | 1.5KW Panasonic servo motor |
| 機器重量： | ≈1450kg | Machine weight: | ≈1450kg |
